Programmable input:
- temperature Pt100, Pt1000, J, K, N, E, R, S
- resistance 400Ω, 4000Ω
- current: ±20mA
- voltage: ±10V, ±60mV, ±150mV, ±300mV
- potentiometric transmitter
Output:
- 1 x relay NC
- 1 x auxillary supply 24V d.c./24 mA
- 1 x RS-485
Features:
- Universal input for measuring: temperature, resistance, standard signals
- Two-line LCD display with high contrast and built-in backlighting
- Possibility of displaying the measured value and time simultaneously or an uncalculated quantity or unit (programmable unit of measured quantity)
- Meter programming from keyboard or through the RS-485 interface by means of the free eCon software.
- 1x alarm output with signaling on led diode, working in 7 different modes
- Memory of minimal and maximal values for all measured quantities
- Supply of object transducers 24V d.c.
- 32-point individual characteristic for the measured value
- Mathematical functions for converting the measured value.
